NCERT Solutions for Maths Chapter 11 Construction Class 10th Excercise: 11.1
In each of the following, give the justification of the construction also:
Q1 Draw a line segment of length 7.6 cm and divide it in the ratio 5 : 8. Measure the two parts.
Answer:
Steps of construction:-
(i) Draw a line segment AB of measurement 7.6 cm (length).
(ii) Now draw an acute angle AC with line segment AB.
(iii) Now cut 13 equal points on the line AC where the zeroth point is A.
(iv) Join the 13th point with point B. So the new line is BA 13 .
(v) Now, from point A 5 draw a line parallel to BA 13 on line AB. Name the point as D.
The point D is the required point which divides the line segment in the ratio of 5: 8.
The length of the two parts obtained is 2.9 cm and 4.7 cm for AD and DB respectively.
Justification:- In the figure, we can see two similar triangles: $\Delta ADA_5$ and $\Delta ABA_{13}$
Thus $\frac{AA_5}{A_5A_{13}}\ =\ \frac{AD}{DB}\ =\ \frac{5}{8}$ .
Answer:
Steps of construction are:-
(i) Firstly draw a line segment AB of length 4 cm.
(ii) Now cut an arc of radius 5 cm from point A and an arc of 6 cm from point B.
(iii) Name the point of intersection of arcs to be point C.
(iv) Now join point AC and BC. Thus $\Delta$ ABC is the required triangle.
(v) Draw a line AD which makes an acute angle with AB and is opposite of vertex C.
(vi) Cut three equal parts of line AD namely AA 1 , AA 2 , AA 3 .
(vii) Now join A 3 to B. Draw a line A 2 B' parallel to A 3 B.
(viii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
Answer:
Steps of construction are:-
(i) Firstly draw a line segment AB of length 5 cm.
(ii) Now cut an arc of radius 6 cm from point A and an arc of 7 cm from point B.
(iii) Name the point of intersection of arcs to be point C.
(iv) Now join point AC and BC. Thus $\Delta$ ABC is the required triangle.
(v) Draw a line AD which makes an acute angle with AB and is opposite of vertex C.
(vi) Cut seven equal parts of line AD namely AA 1 , AA 2 , AA 3 , AA 4 , AA 5 , AA 6 , AA 7 ,.
(vii) Now join A 5 to B. Draw a line A 7 B' parallel to A 5 B.
(viii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
Answer:
Steps of construction:-
(i) Draw a line segment AB of length 8 cm.
(ii) Cut arcs taking point A and point B as the center. Draw the line to intersect on line segment AB. Mark the intersecting point as point D.
(iii) Cut arc of length 4 cm on the same line which will be the altitude of the triangle.
(iv) Name the point as C. Then $\Delta$ ABC is the isosceles triangle.
(v) Draw a line AX which makes an acute angle with AB and is opposite of vertex C.
(vi) Cut seven equal parts of line AX namely AA 1 , AA 2 , AA 3 .
(vii) Now join A 2 to B. Draw a line A 3 B' parallel to A 2 B.
(viii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
Answer:
Steps of construction:-
(i) Draw a line segment BC with a measurement of 6 cm.
(ii) Now construct angle 60 o from point B and draw AB = 5 cm.
(iii) Join point C with point A. Thus $\Delta$ ABC is the required triangle.
(iv) Draw a line BX which makes an acute angle with BC and is opposite of vertex A.
(v) Cut four equal parts of line BX namely BB 1 , BB 2 , BB 3 , BB 4.
(vi) Now join B 4 to C. Draw a line B 3 C' parallel to B 4 C.
(vii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
Answer:
Steps of construction:-
(i) Draw a line segment BC.
(ii) Now draw an angle $\angle$ B = 45 o and $\angle$ C = 30 o and draw rays in these directions.
(iii) Name the intersection of these lines as A.
(iv) Thus $\bigtriangleup ABC$ is the required triangle.
(v) Draw a line BX which makes an acute angle with BC and is opposite of vertex A.
(vi) Cut four equal parts of line BX namely BB 1 , BB 2 , BB 3 , BB 4.
(vii) Now join B 3 to C. Draw a line B 4 C' parallel to B 3 C.
(viii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
Answer:
Steps of construction:-
(i) Draw a line segment AB having a length of 4 cm.
(ii) Now, construct a right angle at point A and make a line of 3 cm.
(iii) Name this point C. Thus $\Delta$ ABC is the required triangle.
(iv) Draw a line AX which makes an acute angle with AB and is opposite of vertex C.
(v) Cut four equal parts of line AX namely AA 1 , AA 2 , AA 3 , AA 4 , AA 5 .
(vi) Now join A 3 to B. Draw a line A 5 B' parallel to A 3 B.
(vii) And then draw a line B'C' parallel to BC.
Hence $\Delta$ AB'C' is the required triangle.
NCERT Solutions for Chapter 11 Class 10 construction Excercise: 11.2
Q1 In each of the following, give also the justification of the construction:
Draw a circle of radius 6 cm. From a point 10 cm away from its center, construct the pair of tangents to the circle and measure their lengths.
Answer:
Steps of construction:-
(i) Taking point O as center draw a circle of radius 6 cm.
(ii) Now, name a point P which is 10 cm away from point O. Join OP.
(iii) Draw a perpendicular bisector of OP name the intersection point of bisector and OP as O'.
(iv) Now draw a circle considering O' as center and O'P as the radius.
(v) Name the intersection point of circles as Q and R.
(vi) Join PQ and PR. These are the required tangents.
(vii) Measure lengths of PQ = 8cm and PR = 8cm
Answer:
Steps of constructions:-
(i) Taking point O as a center draw a circle of radius 4 cm.
(ii) Now taking O as center draw a concentric circle of radius 6 cm.
(iii) Taking any point P on the outer circle, join OP.
(iv) Draw a perpendicular bisector of OP.
(v) Name the intersection of bisector and OP as O'.
(vi) Now, draw a circle taking O' as center and O'P as the radius.
(vii) Name the intersection point of two circles as R and Q.
(viii) Join PR and PQ. These are the required tangents.
(ix) Measure the lengths of the tangents. PR = 4.47 cm and PQ = 4.47 cm.
Answer:
Steps of construction:-
(i) Taking O as a center draw a circle of radius 3 cm.
(ii) Now draw a diameter PQ of this circle and extend it.
(iii) Mark two points R and S on the extended diameter such that OR = OS = 7 cm.
(iv) Draw the perpendicular bisector of both the lines and name their mid-points as T and U.
(v) Now, taking T and U as center draw circles of radius TR and QS.
(vi) Name the intersecting points of the circles with the first circles as V, W, X, Y.
(vii) Join the lines. These are the required tangents.
Answer:
Steps of construction:-
(i) Draw a circle with center O and radius 5 cm.
(ii) Now mark a point A on the circumference of the circle. And draw a line AP perpendicular to the radius OA.
(iii) Mark a point B on the circumference of the circle such that $\angle$ AOB = 120 o . (As we know, the angle at the center is double that of the angle made by tangents).
(iv) Join B to point P.
(v) AP and BP are the required tangents.
Answer:
Steps of construction:-
(i) Draw a line segment AB having a length of 8 cm.
(ii) Now, taking A as a center draw a circle of radius 4 cm. And taking B as a center draw a circle of radius 3 cm.
(iii) Bisect the line AB and name the mid-point as C.
(iv) Taking C as a center and AC as radius draw a circle.
(v) Name the intersection points of the circle as P, Q, R, S.
(vi) Join the lines and these are our required tangents.
Answer:
Steps of construction:-
(i) Draw a line segment BC of length 8 cm.
(ii) Construct a right angle at point B. Now draw a line of length 6 cm. Name the other point as A.
(iii) Join AC. $\Delta$ ABC is the required triangle.
(iv) Now construct a line BD on the line segment AC such that BD is perpendicular to AC.
(v) Now draw a circle taking E as a center (E is the midpoint of line BC) and BE as the radius.
(vi) Join AE. And draw a perpendicular bisector of this line.
(vii) Name the midpoint of AE as F.
(viii) Now, draw a circle with F as center and AF as the radius.
(ix) Name the intersection point of both the circles as G.
(x) Join AG. Thus AB and AG are the required tangents.
Answer:
Steps of construction:-
(i) Draw a circle using a bangle.
(ii) Now draw 2 chords of this circle as QR and ST.
(iii) Take a point P outside the circle.
(iv) Draw perpendicular bisector of both the chords and let them meet at point O.
(v) Joinpoint PO.
(vi) Draw bisector of PO and name the midpoint as U.
(vii) Now, taking U as a center and UP as radius draw a circle.
(viii) Name the intersection point of both the circles as V and W.
(ix) Join PV and PW. These are the required tangents.
