NCERT Solutions for Class 10 Maths Chapter 6 Triangles

We have seen clothes hangers, sandwiches, traffic signboards, etc. Do you know which shape they represent? All these things are triangular. Triangles are fundamental geometric 2-D shapes characterized by three sides, three angles and a sum of 180 degrees for their interior angles. It is the polygon with the least number of sides. In this chapter you will learn about different kind of triangles and their amazing properties.

The NCERT Solutions for Class 10 Maths Chapter 6 will offer stepwise calculations with detailed explanations. These NCERT solutions will help you grasp the concepts through solved questions and will help you improve your accuracy. These are designed as per the latest CBSE syllabus to help you in your upcoming board exams. Let us understand NCERT in better way!

New: Get up to 90% Scholarship on NEET/JEE Coaching from top Coaching Institutes

Don't Miss: JEE Main & NEET 2026 Scholarship Test (Class 10): Narayana | Aakash

Suggested: Important Maths Formulas for Class 10 Maths CBSE

This Story also Contains

1. NCERT Solutions for Class 10 Maths Chapter 6 Triangles PDF Free Download
2. NCERT Class 10 triangle solution- Important Notes
3. NCERT Solutions for Class 10 Maths Chapter 6 Triangles (Exercise)
4. NCERT Solutions for Class 10 Maths: Chapter Wise
5. NCERT Solutions Of Class 10 - Subject Wise
6. NCERT Books and NCERT Syllabus
7. NCERT Exemplar Solutions - Subject Wise

NCERT Solutions for Class 10 Maths Chapter 6 Triangles PDF Free Download

Download PDF

Types of Triangles:

Based on the sides, we have 3 triangles:

• Equilateral Triangles: Triangles that have all 3 sides equal also all the interior angles equal then it is known as equilateral triangles.
• Isosceles Triangle: Triangles that have only two sides equal in length also have angles opposite to the equal side that are equal. It is known as the Isosceles Triangle.
• Scalene Triangle: Triangles that don’t have any equal sides or angles are called scalene triangles.

Based on the measurement of the angle, we have 3 triangles:

• Acute Angle Triangle: Triangles that have all the angles measuring less than 90 degrees is called the Acute Angle Triangle.
• Right Angle Triangle: Triangles that have one angle measuring 90 degrees are called Right Angled Triangles.
• Obtuse Angle Triangle: Triangles that have one angle measuring more than 90 degrees and other angles less than 90 degrees are called Obtuse Angle Triangles.

Similarity Of Triangle:

Two triangles are similar if they have the same ratio of corresponding sides and an equal pair of corresponding angles.

Criteria for Triangle Similarity:

• Angle-Angle-Angle (AAA) Similarity: If the three angles of one triangle are equal to the three angles of another triangle, the triangles are similar.
• Side-Angle-Side (SAS) Similarity- If one angle of a triangle is equal to one angle of another triangle and the two sides including these angles are in the same ratio then the triangles are similar.
• Side-Side-Side (SSS) Similarity- If the corresponding sides of two triangles are in the same ratio then the triangles are similar.
• Right Angle-Hypotenuse-Side(RHS) Similarity- If in two right-angled triangles, the hypotenuse and one corresponding side are in the same ratio then the two triangles are similar.

Important Theorem's

Theorem 6.1- If a line is drawn parallel to one side of a triangle and it cuts the other two sides at different points it will divide those two sides in the same ratio.

Theorem 6.2- If a line divides two sides of a triangle in the same ratio then the line is parallel to the third side of the triangle.

Theorem 6.3- If two triangles have their corresponding angles equal, then their corresponding sides are in the same ratio which means the two triangles are similar.

Theorem 6.4- If the sides of one triangle are in the same ratio as the sides of another triangle, then their corresponding angles are also equal that makes the two triangles similar.

Theorem 6.5- If one angle of a triangle is equal to one angle of another triangle and the sides around these angles are in the same ratio then the two triangles are similar.

NCERT Solutions for Class 10 Maths Chapter 6 Triangles (Exercise)

Maths Chapter 6 Triangles class 10 Exercise: 6.1

Q1 (1) Fill in the blanks using the correct word given in brackets: All circles are ______ . (congruent, similar)

Answer:

All circles are similar.

Since all the circles have a similar shape. They may have different radii, but the shape of all circles is the same.

Therefore, all circles are similar.

Q1 (2) Fill in the blanks using the correct word given in brackets: All squares are ______. (similar, congruent)

Answer:

All squares are similar.

Since all the squares have a similar shape. They may have a different side, but the shape of all squares is the same.

Therefore, all squares are similar.

Q1 (3) Fill in the blanks using the correct word given in brackets: All ______triangles are similar. (isosceles, equilateral)

Answer:

All equilateral triangles are similar.

Since all the equilateral triangles have a similar shape. They may have different sides, but the shape of all equilateral triangles is the same.

Therefore, all equilateral triangles are similar.

Q1 (4) Fill in the blanks using the correct word given in brackets : (iv) Two polygons of the same number of sides are similar if(a) there corresponding angles are _________and (b) their corresponding sides are________. (equal, proportional)

Answer:

Two polygons of the same number of sides are similar if their corresponding angles are equal and their corresponding sides are proportional.

Thus, (a) equal

(b) proportional

Q2 (1) Give two different examples of a pair of similar figures.

Answer:

The two different examples of a pair of similar figures are :

1. Two circles with different radii.

2. Two rectangles with different breadth and length.

Q2 (2) Give two different examples of a pair of non-similar figures.

Answer:

The two different examples of a pair of non-similar figures are :

1. Rectangle and circle

2. A circle and a triangle.

Q3 State whether the following quadrilaterals are similar or not:

Answer:

Quadrilateral PQRS and ABCD are not similar as their corresponding sides are proportional, i.e. $1:2$, but their corresponding angles are not equal.

Class 10 Maths Chapter 6 Triangles Exercise: 6.2

Q1 In Fig. 6.17, (i) and (ii), DE || BC. Find EC in (i) and AD in (ii).

Answer:

(i)

Let EC be x

Given: DE || BC

By using the proportionality theorem, we get

$\frac{AD}{DB}=\frac{AE}{EC}$

$\Rightarrow \frac{1.5}{3}=\frac{1}{x}$

$\Rightarrow x=\frac{3}{1.5}=2cm$

$\therefore EC=2cm$

(ii)

Let AD be x

Given: DE || BC

By using the proportionality theorem, we get

$\frac{AD}{DB}=\frac{AE}{EC}$

$\Rightarrow \frac{x}{7.2}=\frac{1.8}{5.4}$

$\Rightarrow x=\frac{7.2}{3}=2.4cm$

$\therefore AD=2.4cm$

Q2 (1) E and F are points on the sides PQ and PR respectively of a $\mathrm{△}$ PQR. For each of the following cases, state whether EF || QR: PE = 3.9 cm, EQ = 3 cm, PF = 3.6 cm and FR = 2.4 cm

Answer:

(i)

Given :

PE = 3.9 cm, EQ = 3 cm, PF = 3.6 cm and FR = 2.4 cm

$\frac{PE}{EQ}=\frac{3.9}{3}=1.3cm$ and $\frac{PF}{FR}=\frac{3.6}{2.4}=1.5cm$

We have

$\frac{PE}{EQ}\ne \frac{PF}{FR}$

Hence, EF is not parallel to QR.

Q2 (2) E and F are points on the sides PQ and PR, respectively, of a triangle PQR. For each of the following cases, state whether EF || QR : PE = 4 cm, QE = 4.5 cm, PF = 8 cm and RF = 9 cm

Answer:

(ii)

Given :

PE = 4 cm, QE = 4.5 cm, PF = 8 cm and RF = 9 cm

$\frac{PE}{EQ}=\frac{4}{4.5}=\frac{8}{9}cm$ and $\frac{PF}{FR}=\frac{8}{9}cm$

We have

$\frac{PE}{EQ}=\frac{PF}{FR}$

Hence, EF is parallel to QR.

Q2 (3) E and F are points on the sides PQ and PR, respectively, of a triangle PQR. For each of the following cases, state whether EF || QR : PQ = 1.28 cm, PR = 2.56 cm, PE = 0.18 cm and PF = 0.36 cm

Answer:

(iii)

Given :

PQ = 1.28 cm, PR = 2.56 cm, PE = 0.18 cm and PF = 0.36 cm

$\frac{PE}{PQ}=\frac{0.18}{1.28}=\frac{9}{64}cm$ and $\frac{PF}{PR}=\frac{0.36}{2.56}=\frac{9}{64}cm$

We have

$\frac{PE}{EQ}=\frac{PF}{FR}$

Hence, EF is parallel to QR.

Q3 In Fig. 6.18, if LM || CB and LN || CD, prove that $\frac{AM}{AB}=\frac{AN}{AD}$

Answer:

Given : LM || CB and LN || CD

To prove :

$\frac{AM}{AB}=\frac{AN}{AD}$

Since , LM || CB so we have

$\frac{AM}{AB}=\frac{AL}{AC}.............................................1$

Also, LN || CD

$\frac{AL}{AC}=\frac{AN}{AD}.............................................2$

From equations 1 and 2, we have

$\frac{AM}{AB}=\frac{AN}{AD}$

Hence proved.

Q4 In Fig. 6.19, DE || AC and DF || AE. Prove that BF / FE = BE / EC

Answer:

Given: DE || AC and DF || AE.

To prove :

$\frac{BF}{FE}=\frac{BE}{EC}$

Since , DE || AC so we have

$\frac{BD}{DA}=\frac{BE}{EC}.............................................1$

Also, DF || AE

$\frac{BD}{DA}=\frac{BF}{FE}.............................................2$

From equations 1 and 2, we have

$\frac{BF}{FE}=\frac{BE}{EC}$

Hence proved.

Q5 In Fig. 6.20, DE || OQ and DF || OR. Show that EF || QR.

Answer:

Given: DE || OQ and DF || OR.

To prove EF || QR.

Since DE || OQ so we have

$\frac{PE}{EQ}=\frac{PD}{DO}.............................................1$

Also, DF || OR

$\frac{PF}{FR}=\frac{PD}{DO}.............................................2$

From equations 1 and 2, we have

$\frac{PE}{EQ}=\frac{PF}{FR}$

Thus, EF || QR. (converse of basic proportionality theorem)

Hence proved.

Q6 In Fig. 6.21, A, B, and C are points on OP, OQ and OR respectively such that AB || PQ and AC || PR. Show that BC || QR.

Answer:

Given : AB || PQ and AC || PR

To prove: BC || QR

Since, AB || PQ so we have

$\frac{OA}{AP}=\frac{OB}{BQ}.............................................1$

Also, AC || PR

$\frac{OA}{AP}=\frac{OC}{CR}.............................................2$

From equations 1 and 2, we have

$\frac{OB}{BQ}=\frac{OC}{CR}$

Therefore, BC || QR. (converse basic proportionality theorem)

Hence proved.

Q7 Using Theorem 6.1, prove that a line drawn through the mid-point of one side of a triangle parallel to another side bisects the third side. (Recall that you have proved it in Class IX.)

Answer:

Let PQ be a line passing through the midpoint of line AB and parallel to line BC, intersecting line AC at point Q.

i.e. $PQ||BC$ and $AP=PB$ .

Using the basic proportionality theorem, we have

$\frac{AP}{PB}=\frac{AQ}{QC}..........................1$

Since $AP=PB$

$\frac{AQ}{QC}=\frac{1}{1}$

$\Rightarrow AQ=QC$

$\therefore$ Q is the midpoint of AC.

Q8 Using Theorem 6.2, prove that the line joining the midpoints of any two sides of a triangle is parallel to the third side. (Recall that you have done it in Class IX.)

Answer:

Let P be the midpoint of line AB and Q be the midpoint of line AC.

PQ is the line joining midpoints P and Q of lines AB and AC, respectively.

i.e. $AQ=QC$ and $AP=PB$ .

we have,

$\frac{AP}{PB}=\frac{1}{1}..........................1$

$\frac{AQ}{QC}=\frac{1}{1}...................................2$

From equations 1 and 2, we get

$\frac{AQ}{QC}=\frac{AP}{PB}$

$\therefore$ By basic proportionality theorem, we have $PQ||BC$

Q9 ABCD is a trapezium in which AB || DC and its diagonals intersect each other at the point O. Show
that $\frac{AO}{BO}=\frac{CO}{DO}$

Answer:

Draw a line EF passing through point O such that $EO||CDandFO||CD$

To prove :

$\frac{AO}{BO}=\frac{CO}{DO}$

In $\mathrm{△}ADC$ , we have $CD||EO$

So, by using the basic proportionality theorem,

$\frac{AE}{ED}=\frac{AO}{OC}........................................1$

In $\mathrm{△}ABD$ , we have $AB||EO$

So, by using the basic proportionality theorem,

$\frac{DE}{EA}=\frac{OD}{BO}........................................2$

Using equations 1 and 2, we get

$\frac{AO}{OC}=\frac{BO}{OD}$

$\Rightarrow \frac{AO}{BO}=\frac{CO}{DO}$

Hence proved.

Q10 The diagonals of a quadrilateral ABCD intersect each other at point O such that $\frac{AO}{BO}=\frac{CO}{DO}$. Show that ABCD is a trapezium.

Answer:

Draw a line EF passing through point O such that $EO||AB$

Given :

$\frac{AO}{BO}=\frac{CO}{DO}$

In $\mathrm{△}ABD$ , we have $AB||EO$

So, by using the basic proportionality theorem,

$\frac{AE}{ED}=\frac{BO}{DO}........................................1$

However, it is given that

$\frac{AO}{CO}=\frac{BO}{DO}..............................2$

Using equations 1 and 2, we get

$\frac{AE}{ED}=\frac{AO}{CO}$

$\Rightarrow EO||CD$ (By basic proportionality theorem)

$\Rightarrow AB||EO||CD$

$\Rightarrow AB||CD$

Therefore, ABCD is a trapezium.

Class 10 Maths Chapter 6 Triangles Exercise: 6.3

Q1 State which pairs of triangles in Fig. 6.34 are similar. Write the similarity criterion used by you for answering the question, and also write the pairs of similar triangles in the symbolic form :

Answer:

(i) $\mathrm{\angle }A=\mathrm{\angle }P={60}^{\circ }$

$\mathrm{\angle }B=\mathrm{\angle }Q={80}^{\circ }$

$\mathrm{\angle }C=\mathrm{\angle }R={40}^{\circ }$

$\therefore \mathrm{△}ABC\sim \mathrm{△}PQR$ (By AAA)

So , $\frac{AB}{QR}=\frac{BC}{RP}=\frac{CA}{PQ}$

(ii) As corresponding sides of both triangles are proportional.

$\therefore \mathrm{△}ABC\sim \mathrm{△}PQR$ (By SSS)

(iii) Given triangles are not similar because corresponding sides are not proportional.

(iv) $\mathrm{△}MNL\sim \mathrm{△}PQR$ by SAS similarity criteria.

(v) Given triangles are not similar because the corresponding angle is not contained by two corresponding sides

(vi) In $\mathrm{△}DEF$ , we know that

$\mathrm{\angle }D+\mathrm{\angle }E+\mathrm{\angle }F={180}^{\circ }$

$\Rightarrow {70}^{\circ }+{80}^{\circ }+\mathrm{\angle }F={180}^{\circ }$

$\Rightarrow {150}^{\circ }+\mathrm{\angle }F={180}^{\circ }$

$\Rightarrow \mathrm{\angle }F={180}^{\circ }-{150}^{\circ }={30}^{\circ }$

In $\mathrm{△}PQR$ , we know that

$\mathrm{\angle }P+\mathrm{\angle }Q+\mathrm{\angle }R={180}^{\circ }$

$\Rightarrow {30}^{\circ }+{80}^{\circ }+\mathrm{\angle }R={180}^{\circ }$

$\Rightarrow {110}^{\circ }+\mathrm{\angle }R={180}^{\circ }$

$\Rightarrow \mathrm{\angle }R={180}^{\circ }-{110}^{\circ }={70}^{\circ }$

$\mathrm{\angle }Q=\mathrm{\angle }P={70}^{\circ }$

$\mathrm{\angle }E=\mathrm{\angle }Q={80}^{\circ }$

$\mathrm{\angle }F=\mathrm{\angle }R={30}^{\circ }$

$\therefore \mathrm{△}DEF\sim \mathrm{△}PQR$ ( By AAA)

Q2 In Fig. 6.35, $\mathrm{\Delta }ODC\sim \mathrm{\Delta }OBA$ , $\mathrm{\angle }BOC={125}^{\circ }$ and $\mathrm{\angle }CDO={70}^{\circ }$ . Find $\mathrm{\angle }DOC,\mathrm{\angle }DCO,\mathrm{\angle }OAB$

Answer:

Given : $\mathrm{\Delta }ODC\sim \mathrm{\Delta }OBA$ , $\mathrm{\angle }BOC={125}^{\circ }$ and $\mathrm{\angle }CDO={70}^{\circ }$

$\mathrm{\angle }DOC+\mathrm{\angle }BOC={180}^{\circ }$ (DOB is a straight line)

$\Rightarrow \mathrm{\angle }DOC+{125}^{\circ }={180}^{\circ }$

$\Rightarrow \mathrm{\angle }DOC={180}^{\circ }-{125}^{\circ }$

$\Rightarrow \mathrm{\angle }DOC={55}^{\circ }$

In $\mathrm{\Delta }ODC,$

$\mathrm{\angle }DOC+\mathrm{\angle }ODC+\mathrm{\angle }DCO={180}^{\circ }$

$\Rightarrow {55}^{\circ }+{70}^{\circ }+\mathrm{\angle }DCO={180}^{\circ }$

$\Rightarrow \mathrm{\angle }DCO+{125}^{\circ }={180}^{\circ }$

$\Rightarrow \mathrm{\angle }DCO={180}^{\circ }-{125}^{\circ }$

$\Rightarrow \mathrm{\angle }DCO={55}^{\circ }$

Since, $\mathrm{\Delta }ODC\sim \mathrm{\Delta }OBA$, so

$\Rightarrow \mathrm{\angle }OAB=\mathrm{\angle }DCO={55}^{\circ }$ (Corresponding angles are equal in similar triangles).

Q3 Diagonals AC and BD of a trapezium ABCD with AB || DC intersect each other at the point O. Using a similarity criterion for two triangles, show that $\frac{OA}{OC}=\frac{OB}{OD}$

Answer:

In $\mathrm{△}DOCand\mathrm{△}BOA$ , we have

$\mathrm{\angle }CDO=\mathrm{\angle }ABO$ ( Alternate interior angles as $AB||CD$ )

$\mathrm{\angle }DCO=\mathrm{\angle }BAO$ ( Alternate interior angles as $AB||CD$ )

$\mathrm{\angle }DOC=\mathrm{\angle }BOA$ ( Vertically opposite angles are equal)

$\therefore \mathrm{△}DOC\sim \mathrm{△}BOA$ ( By AAA)

$\therefore \frac{DO}{BO}=\frac{OC}{OA}$ ( corresponding sides are equal)

$\Rightarrow \frac{OA}{OC}=\frac{OB}{OD}$

Hence proved.

Q4 In Fig. 6.36, $\frac{QR}{QS}=\frac{QT}{PR}$ and $\mathrm{\angle }1=\mathrm{\angle }2$ . Show that $\mathrm{\Delta }PQS\sim \mathrm{\Delta }TQR$

Answer:

Given : $\frac{QR}{QS}=\frac{QT}{PR}$ and $\mathrm{\angle }1=\mathrm{\angle }2$

To prove : $\mathrm{\Delta }PQS\sim \mathrm{\Delta }TQR$

In $\mathrm{△}PQR$ , $\mathrm{\angle }PQR=\mathrm{\angle }PRQ$

$\therefore PQ=PR$

$\frac{QR}{QS}=\frac{QT}{PR}$ (Given)

$\Rightarrow \frac{QR}{QS}=\frac{QT}{PQ}$

In $\mathrm{\Delta }PQSand\mathrm{\Delta }TQR$,

$\Rightarrow \frac{QR}{QS}=\frac{QT}{PQ}$

$\mathrm{\angle }Q=\mathrm{\angle }Q$ (Common)

$\mathrm{\Delta }PQS\sim \mathrm{\Delta }TQR$ (By SAS)

Q5 S and T are points on sides PR and QR of $\mathrm{\Delta }$ PQR such that $\mathrm{\angle }$ P = $\mathrm{\angle }$ RTS. Show that $\mathrm{\Delta }$ RPQ ~ $\mathrm{\Delta }$ RTS.

Answer:

Given : $\mathrm{\angle }$ P = $\mathrm{\angle }$ RTS

To prove RPQ ~ $\mathrm{\Delta }$ RTS.

In $\mathrm{\Delta }$ RPQ and $\mathrm{\Delta }$ RTS,

$\mathrm{\angle }$ P = $\mathrm{\angle }$ RTS (Given)

$\mathrm{\angle }$ R = $\mathrm{\angle }$ R (common)

$\mathrm{\Delta }$ RPQ ~ $\mathrm{\Delta }$ RTS. (By AA)

Q6 In Fig. 6.37, if $\mathrm{\Delta }$ ABE $\equiv$ $\mathrm{\Delta }$ ACD, show that $\mathrm{\Delta }$ ADE ~ $\mathrm{\Delta }$ ABC.

Answer:

Given: $\mathrm{△}ABE\cong \mathrm{△}ACD$

To prove ADE ~ $\mathrm{\Delta }$ ABC.

Since $\mathrm{△}ABE\cong \mathrm{△}ACD$

$AB=AC$ (By CPCT)

$AD=AE$ (By CPCT)

In $\mathrm{\Delta }$ ADE and $\mathrm{\Delta }$ ABC,

$\mathrm{\angle }A=\mathrm{\angle }A$ (Common)

and

$\frac{AD}{AB}=\frac{AE}{AC}$ ( $AB=AC$ and $AD=AE$ )

Therefore, $\mathrm{\Delta }$ ADE ~ $\mathrm{\Delta }$ ABC. ( By SAS criteria)

Q7 (1) In Fig. 6.38, altitudes AD and CE of $\mathrm{\Delta }ABC$ intersect each other at the point P. Show that: $\mathrm{\Delta }AEP\sim \mathrm{\Delta }CDP$

Answer:

To prove : $\mathrm{\Delta }AEP\sim \mathrm{\Delta }CDP$

In $\mathrm{\Delta }AEPand\mathrm{\Delta }CDP$ ,

$\mathrm{\angle }AEP=\mathrm{\angle }CDP$ ( Both angles are right angle)

$\mathrm{\angle }APE=\mathrm{\angle }CPD$ (Vertically opposite angles )

$\mathrm{\Delta }AEP\sim \mathrm{\Delta }CDP$ ( By AA criterion)

Q7 (2) In Fig. 6.38, altitudes AD and CE of $\mathrm{\Delta }ABC$ intersect each other at the point P. Show that: $\mathrm{\Delta }ABD\sim \mathrm{\Delta }CBE$

Answer:

To prove : $\mathrm{\Delta }ABD\sim \mathrm{\Delta }CBE$

In $\mathrm{\Delta }ABDand\mathrm{\Delta }CBE$ ,

$\mathrm{\angle }ADB=\mathrm{\angle }CEB$ ( Both angles are right angle)

$\mathrm{\angle }ABD=\mathrm{\angle }CBE$ (Common )

$\mathrm{\Delta }ABD\sim \mathrm{\Delta }CBE$ ( By AA criterion)

Q7 (3) In Fig. 6.38, altitudes AD and CE of $\mathrm{\Delta }ABC$ intersect each other at the point P. Show that: $\mathrm{\Delta }AEP\sim \mathrm{\Delta }ADB$

Answer:

To prove : $\mathrm{\Delta }AEP\sim \mathrm{\Delta }ADB$

In $\mathrm{\Delta }AEPand\mathrm{\Delta }ADB$ ,

$\mathrm{\angle }AEP=\mathrm{\angle }ADB$ ( Both angles are right angle)

$\mathrm{\angle }A=\mathrm{\angle }A$ (Common )

$\mathrm{\Delta }AEP\sim \mathrm{\Delta }ADB$ ( By AA criterion)

Q7 (4) In Fig. 6.38, altitudes AD and CE of $\mathrm{\Delta }ABC$ intersect each other at the point P. Show that: $\mathrm{\Delta }PDC\sim \mathrm{\Delta }BEC$

Answer:

To prove : $\mathrm{\Delta }PDC\sim \mathrm{\Delta }BEC$

In $\mathrm{\Delta }PDCand\mathrm{\Delta }BEC$ ,

$\mathrm{\angle }CDP=\mathrm{\angle }CEB$ ( Both angles are right angle)

$\mathrm{\angle }C=\mathrm{\angle }C$ (Common )

$\mathrm{\Delta }PDC\sim \mathrm{\Delta }BEC$ ( By AA criterion)

Q8 E is a point on the side AD produced of a parallelogram ABCD, and BE intersects CD at F. Show that $\mathrm{\Delta }ABE\sim \mathrm{\Delta }CFB$.

Answer:

To prove : $\mathrm{\Delta }ABE\sim \mathrm{\Delta }CFB$

In $\mathrm{\Delta }ABEand\mathrm{\Delta }CFB$ ,

$\mathrm{\angle }A=\mathrm{\angle }C$ ( Opposite angles of a parallelogram are equal)

$\mathrm{\angle }AEB=\mathrm{\angle }CBF$ ( Alternate angles of AE||BC)

$\mathrm{\Delta }ABE\sim \mathrm{\Delta }CFB$ ( By AA criterion )

Q9 (1) In Fig. 6.39, ABC and AMP are two right triangles, right-angled at B and M, respectively. Prove that: $\mathrm{\Delta }ABC\sim \mathrm{\Delta }AMP$

Answer:

To prove : $\mathrm{\Delta }ABC\sim \mathrm{\Delta }AMP$

In $\mathrm{\Delta }ABCand\mathrm{\Delta }AMP$ ,

$\mathrm{\angle }ABC=\mathrm{\angle }AMP$ ( Each ${90}^{\circ }$ )

$\mathrm{\angle }A=\mathrm{\angle }A$ ( common)

$\mathrm{\Delta }ABC\sim \mathrm{\Delta }AMP$ ( By AA criterion )

Q9 In Fig. 6.39, ABC and AMP are two right triangles, right-angled at B and M, respectively. Prove that $\frac{CA}{PA}=\frac{BC}{MP}$

Answer:

To prove :

$\frac{CA}{PA}=\frac{BC}{MP}$

In $\mathrm{\Delta }ABCand\mathrm{\Delta }AMP$ ,

$\mathrm{\angle }ABC=\mathrm{\angle }AMP$ ( Each ${90}^{\circ }$ )

$\mathrm{\angle }A=\mathrm{\angle }A$ ( common)

$\mathrm{\Delta }ABC\sim \mathrm{\Delta }AMP$ ( By AA criterion )

$\frac{CA}{PA}=\frac{BC}{MP}$ ( corresponding parts of similar triangles )

Hence proved.

Q10 (1) CD and GH are respectively the bisectors of $\mathrm{\angle }ACB$ and $\mathrm{\angle }EGF$ such that D and H lie on sides AB and FE of $\mathrm{\Delta }ABCand\mathrm{\Delta }EGF$ respectively. If $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$ , show that: $\frac{CD}{GH}=\frac{AC}{FG}$

Answer:

To prove :

$\frac{CD}{GH}=\frac{AC}{FG}$

Given : $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$

$\mathrm{\angle }A=\mathrm{\angle }F,\mathrm{\angle }B=\mathrm{\angle }Eand\mathrm{\angle }ACB=\mathrm{\angle }FGE,\mathrm{\angle }ACB=\mathrm{\angle }FGE$

$\therefore \mathrm{\angle }ACD=\mathrm{\angle }FGH$ ( CD and GH are bisectors of equal angles)

$\therefore \mathrm{\angle }DCB=\mathrm{\angle }HGE$ ( CD and GH are bisectors of equal angles)

In $\mathrm{\Delta }ACDand\mathrm{\Delta }FGH$

$\therefore \mathrm{\angle }ACD=\mathrm{\angle }FGH$ ( proved above)

$\mathrm{\angle }A=\mathrm{\angle }F$ ( proved above)

$\mathrm{\Delta }ACD\sim \mathrm{\Delta }FGH$ ( By AA criterion)

$\Rightarrow \frac{CD}{GH}=\frac{AC}{FG}$

Hence proved.

Q 10 (2) CD and GH are respectively the bisectors of $\mathrm{\angle }ABCand\mathrm{\angle }EGF$ such that D and H lie on sides AB and FE of $\mathrm{\Delta }ABCand\mathrm{\Delta }EGF$ respectively. If $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$ , show that: $\mathrm{\Delta }DCB\sim \mathrm{\Delta }HGE$

Answer:

To prove : $\mathrm{\Delta }DCB\sim \mathrm{\Delta }HGE$

Given : $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$

In $\mathrm{\Delta }DCBand\mathrm{\Delta }HGE$ ,

$\therefore \mathrm{\angle }DCB=\mathrm{\angle }HGE$ ( CD and GH are bisectors of equal angles)

$\mathrm{\angle }B=\mathrm{\angle }E$ ( $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$ )

$\mathrm{\Delta }DCB\sim \mathrm{\Delta }HGE$ ( By AA criterion )

Q10 (3) CD and GH are respectively the bisectors of $\mathrm{\angle }ABCand\mathrm{\angle }EGF$ such that D and H lie on sides AB and FE of $\mathrm{\Delta }ABCand\mathrm{\Delta }EGF$ respectively. If $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$ , show that: $\mathrm{\Delta }DCA\sim \mathrm{\Delta }HGF$

Answer:

To prove : $\mathrm{\Delta }DCA\sim \mathrm{\Delta }HGF$

Given : $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$

In $\mathrm{\Delta }DCAand\mathrm{\Delta }HGF$ ,

$\therefore \mathrm{\angle }ACD=\mathrm{\angle }FGH$ ( CD and GH are bisectors of equal angles)

$\mathrm{\angle }A=\mathrm{\angle }F$ ( $\mathrm{\Delta }ABC\sim \mathrm{\Delta }EGF$ )

$\mathrm{\Delta }DCA\sim \mathrm{\Delta }HGF$ ( By AA criterion )

Q11 In Fig. 6.40, E is a point on side CB produced of an isosceles triangle ABC with AB = AC. If $AD\perp BC$ and $EF\perp AC$ , prove that $\mathrm{\Delta }ABD\sim \mathrm{\Delta }ECF$

Answer:

To prove : $\mathrm{\Delta }ABD\sim \mathrm{\Delta }ECF$

Given: ABC is an isosceles triangle.

$AB=ACand\mathrm{\angle }B=\mathrm{\angle }C$

In $\mathrm{\Delta }ABDand\mathrm{\Delta }ECF$ ,

$\mathrm{\angle }ABD=\mathrm{\angle }ECF$ ( $\mathrm{\angle }ABD=\mathrm{\angle }B=\mathrm{\angle }C=\mathrm{\angle }ECF$ )

$\mathrm{\angle }ADB=\mathrm{\angle }EFC$ ( Each ${90}^{\circ }$ )

$\mathrm{\Delta }ABD\sim \mathrm{\Delta }ECF$ ( By AA criterion)

Q12 Sides AB and BC and median AD of a triangle ABC are respectively proportional to sides PQ and QR and median PM of $\mathrm{\Delta }PQR$ (see Fig. 6.41). Show that $\mathrm{\Delta }ABC\sim \mathrm{\Delta }PQR$

Answer:

AD and PM are medians of triangles. So,

$BD=\frac{BC}{2}andQM=\frac{QR}{2}$

Given :

$\frac{AB}{PQ}=\frac{BC}{QR}=\frac{AD}{PM}$

$\Rightarrow \frac{AB}{PQ}=\frac{\frac{1}{2}BC}{\frac{1}{2}QR}=\frac{AD}{PM}$

$\Rightarrow \frac{AB}{PQ}=\frac{BD}{QM}=\frac{AD}{PM}$

In $\mathrm{△}ABDand\mathrm{△}PQM,$

$\frac{AB}{PQ}=\frac{BD}{QM}=\frac{AD}{PM}$

$\therefore \mathrm{△}ABD\sim \mathrm{△}PQM,$ (SSS similarity)

$\Rightarrow \mathrm{\angle }ABD=\mathrm{\angle }PQM$ ( Corresponding angles of similar triangles )

In $\mathrm{△}ABCand\mathrm{△}PQR,$

$\Rightarrow \mathrm{\angle }ABD=\mathrm{\angle }PQM$ (proved above)

$\frac{AB}{PQ}=\frac{BC}{QR}$

Therefore, $\mathrm{\Delta }ABC\sim \mathrm{\Delta }PQR$ . ( SAS similarity)

Q13 D is a point on the side BC of a triangle ABC such that $\mathrm{\angle }ADC=\mathrm{\angle }BAC$. Show that $C{A}^2=CB.CD.$

Answer:

In, $\mathrm{△}ADCand\mathrm{△}BAC,$

$\mathrm{\angle }ADC=\mathrm{\angle }BAC$ ( given )

$\mathrm{\angle }ACD=\mathrm{\angle }BCA$ (common )

$\mathrm{△}ADC\sim \mathrm{△}BAC,$ ( By AA rule)

$\frac{CA}{CB}=\frac{CD}{CA}$ ( corresponding sides of similar triangles )

$\Rightarrow C{A}^2=CB\times CD$

Q14 Sides AB and AC and median AD of a triangle ABC are respectively proportional to sides PQ and PR and median PM of another triangle PQR. Show that $\mathrm{\Delta }ABC\sim \mathrm{\Delta }PQR$

Answer:

$\frac{AB}{PQ}=\frac{AC}{PR}=\frac{AD}{PM}$ (given)

Produce AD and PM to E and L such that AD=DE and PM=DE. Now,

join B to E, C to E, Q to L and R to L.

AD and PM are medians of a triangle; therefore

QM=MR and BD=DC

AD = DE (By construction)

PM=ML (By construction)

So, diagonals of ABEC bisecting each other at D, so ABEC is a parallelogram.

Similarly, PQLR is also a parallelogram.

Therefore, AC=BE ,AB=EC and PR=QL,PQ=LR

$\frac{AB}{PQ}=\frac{AC}{PR}=\frac{AD}{PM}$ (Given )

$\Rightarrow \frac{AB}{PQ}=\frac{BE}{QL}=\frac{2.AD}{2.PM}$

$\Rightarrow \frac{AB}{PQ}=\frac{BE}{QL}=\frac{AE}{PL}$

$\mathrm{\Delta }ABE\sim \mathrm{\Delta }PQL$ (SSS similarity)

$\mathrm{\angle }BAE=\mathrm{\angle }QPL$ ...................1 (Corresponding angles of similar triangles)

Similarity, $\mathrm{△}AEC=\mathrm{△}PLR$

$\mathrm{\angle }CAE=\mathrm{\angle }RPL$ ........................2

Adding equations 1 and 2,

$\mathrm{\angle }BAE+\mathrm{\angle }CAE=\mathrm{\angle }QPL+\mathrm{\angle }RPL$

$\mathrm{\angle }CAB=\mathrm{\angle }RPQ$ ............................3

In $\mathrm{△}ABCand\mathrm{△}PQR,$

$\frac{AB}{PQ}=\frac{AC}{PR}$ ( Given )
